Arduino Compatible 8-Digit 7-Segment Display
Technical Overview: YL-3 7-Segment Display
Introduction
The YL-3 7-segment display is a single-digit LED-based numeric display module. It features seven LED segments arranged in a figure-eight configuration and an eighth LED for the decimal point.
Each segment can be individually controlled to form numbers or simple characters.
Key Specifications
| Parameter | Value |
|---|---|
| Display Type | 7-segment LED |
| Configuration | Common Anode or Cathode |
| Number of Digits | 1 |
| Segment Voltage | 1.8V to 2.2V (typical) |
| Segment Current | 10-20mA per segment |
| Operating Temperature | -40°C to +85°C |
| Color | Red |
| Mounting Type | Through-hole |
Physical Characteristics
- Dimensions: 15mm panel height with red 9mm digits
- Material: Plastic encapsulated housing with opaque lens.
- Pin Count: SPI interface
Pinout Description
| Pin | Function |
|---|---|
| 1 | Segment 'a' |
| 2 | Segment 'b' |
| 3 | Segment 'c' |
| 4 | Segment 'd' |
| 5 | Segment 'e' |
| 6 | Segment 'f' |
| 7 | Segment 'g' |
| 8 | Decimal Point (DP) |
| 9, 10 | Common Anode or Cathode |
Operating Principles
The YL-3 7-segment display operates by illuminating specific LED segments to form numbers or basic alphanumeric characters. For example:
- To display the digit "1," segments b and c are activated.
- To display the digit "8," all segments (a to g) are illuminated.
A current-limiting resistor is required in series with each segment to prevent overcurrent damage, typically with values of 220Ω to 330Ω.
Electrical Characteristics
- Forward Voltage (Vf): 1.8V to 2.2V per segment.
- Forward Current (If): 10-20mA per segment.
- Reverse Voltage: Up to 5V.
- Power Dissipation: ~0.2W per segment.
Applications
- Digital clocks
- Timers
- Counters
- Digital meters (voltage, current, etc.)
- DIY and STEM educational projects
Driving the YL-3 Display
The YL-3 display can be driven using the following methods:
- Direct Microcontroller Pins:
- Each segment connects to a GPIO pin.
- Suitable for simple applications.
- Driver ICs:
- MAX7219 for efficient control.
- Reduces GPIO pin usage.
- Multiplexing:
- Allows control of multiple digits with fewer pins.
Advantages
- Low cost and widely available.
- Easy integration with standard circuits.
- Bright and legible output.
Limitations
- Limited to numeric or basic alphanumeric displays.
- Higher power consumption compared to modern display technologies like LCD or OLED.
- Requires additional components (resistors, drivers) for operation.
Conclusion
The YL-3 7-segment display is a versatile, cost-effective solution for numerical data visualization in a wide range of applications. Its simplicity and robust operation make it an ideal choice for hobbyists, educators, and basic industrial uses.
