Green 3mm LED 40mcd Round Diffused

SKU ZD0120
Original price $0.22 - Original price $0.22
Original price
$0.22
$0.22 - $0.22
Current price $0.22
LED

Green 3mm LED 40mCd Round Diffused

Product Dimensions


Diameter
3mm

Packaged Dimensions


Packaged Volume
0l
Packaged Weight
0.001kg
Packaged Length
3.5cm
Packaged Width
0.3cm
Packaged Height
0.3cm

LED Components


Light Colour
Green
Illumination Type
Single Colour
Light Wavelength
573nm
LED Type
3mm Standard LED
Viewing Angle
50°
Intensity
40mcd
Vf (typ) - Typical Forward Voltage
2.3V
Lens Type
Diffused
If (typ) - Typical Forward Current
20mA
If (max) - Maximum Forward Current
20mA
Resistor for 5VDC
130Ω
Resistor for 9VDC
330Ω
Resistor for 12VDC
470Ω

Product Availability


Availability
Stocked item
