6 Pin 0.156in Straight Locking Header with crimp pins - 3.96mm Pitch

SKU HM3446
Original price $0.95 - Original price $0.95
Original price
$0.95
$0.95 - $0.95
Current price $0.95
The contacts are rated at 250V @ 7A AC/DC which makes them an ideal power connector to a PCB. They are end to end stackable and commonly seen as the output connector on Switchmode power supplies.

Features:
- Wire Pull- Out force: 2.85kg
- Unmating Force: 150g
- Durability: 25 cycles
- Housing: Nylon, UL 94V- 2
- Temperature: - 40 to 105°C

Header Connections


Pack Quantity
1pc
Number of Pins
6pc
Pin Size
3.96mm
Type
Single Row Header
Device
Plug
Attachment Method
Crimp
Pin Spacing
4mm (5/32")
header locking
header polarised
Mating Force
199gg
Contact Insertion Force
681g
Contact Retention to Housing
3.63kg

DC Voltage Rating


DC Voltage
250V

DC Current Rating


DC current rating
2.5A

AC Current Rating


AC current rating
2.5A

Product Mounting


Mounting Method
PCB

Measures Temperature


Outdoor / Exterior Scale
-40°C-105°C

Packaged Dimensions


Packaged Volume
0.009375l
Packaged Weight
0.001kg
Packaged Length
2.5cm
Packaged Width
1.5cm
Packaged Height
2.5cm
