10 Pin 0.156in Straight Locking Header with crimp pins - 3.96mm Pitch
SKU HM3450
Original price
$1.19
-
Original price
$1.19
Original price
$1.19
$1.95
$1.95
-
$1.95
Current price
$1.95
The contacts are rated at 250V @ 7A AC/DC which makes them an ideal power connector to a PCB. They are end to end stackable and commonly seen as the output connector on Switchmode power supplies.
Features:
- Wire Pull- Out force: 2.85kg
- Unmating Force: 150g
- Durability: 25 cycles
- Housing: Nylon, UL 94V- 2
- Temperature: - 40 to 105°C
Features:
- Wire Pull- Out force: 2.85kg
- Unmating Force: 150g
- Durability: 25 cycles
- Housing: Nylon, UL 94V- 2
- Temperature: - 40 to 105°C
Operating Temperature and Humidity
| Operating Temperature | 150°C |
Header Connections
| Pack Quantity | 1pc |
| Number of Pins | 10pc |
| Pin Size | 0.1mm |
| Type | Single Row Header |
| Device | Plug |
| Attachment Method | Crimp |
| Pin Spacing | 4mm (5/32") |
| Insulation Dielectric Voltage Rating | 1500V |
| Insulation Resistance | 500MΩ |
| header locking | |
| header polarised | |
| Mating Force | 199gg |
| Contact Insertion Force | 681g |
| Contact Retention to Housing | 3.63kg |
DC Voltage Rating
| DC Voltage | 250V |
DC Current Rating
| DC current rating | 2.5A |
AC Current Rating
| AC current rating | 2.5A |
Product Mounting
| Mounting Method | PCB |
Packaged Dimensions
| Packaged Volume | 0.0072l |
| Packaged Weight | 0.003kg |
| Packaged Length | 4cm |
| Packaged Width | 1.8cm |
| Packaged Height | 1cm |
